Vibrating Viscometer

Wepower offers In-Line and In -tank process vibrating viscometers for in a variety of industrial applications. Rich experiences in both designing and production of fork vibrating viscosity meter, you can rely on us anytime for the professional solutions and technical guidance!

Category: Tuning Fork Viscosity Meter
Share
  • Description

product overview-wepower electronic

The vibrating viscometer can be top-mounted and side-mounted for liquids viscosity and density measurement.It is worth noting that the standard length under the normal connection process is 150mm (the part that must be inserted is at least 130mm), so if you want to customize the immersion length when you want to install our vibrating viscometer at the top of the storage tanks, just let us know the site conditions as well, our professional advice will be helpful for you! Rich experiences in both designing and production of fork vibrating viscosity meter, you can rely on us anytime for the professional solutions and technical guidance.

Wepower offers In-Line and In-tank process vibrating viscometers for in a variety of industrial applications, providing reliable viscosity management to help optimize  production processes and product quality standard.

parameters

Product In-line Process Viscometer /Micro Motion Viscosity Meter/ Vibrating Viscometer
Viscosity Measuring Range 0-20,000cP
Viscosity Accuracy ±0.2cP (0-10cP) then ±1%

Full scale of calibrated range max

±1cP (10-100cP), ±10cP (100-1000cP),

±125cP (1000-12,500cP)

Temperature Accuracy BS1904, DIN 43760 Class ‘B’ (±0.30 ±0.005 X T)°C
Wetted material SS316; PTFE; PFA; tantalum; Hastelloy C
Housing Material Die-casting aluminum/ Stainless Steel
Safety Approvals Explosion/Flame-Proof
Process Connecting Flange, thread, tri-clamp
Display Two-line, LCD screen

Optical switch configuration

Outputs Standard: 4-20mA,  HART, Modbus RS-485
Protection Class Ingress Protection: IP66/67
Dimensions 355 mm (h) x 163 mm (w) x 163 mm (d) (Typical short stem version)
Weight (Typical) 6.7 kg (15 lbs)

product details OKonline viscosity meterFVM -fork viscosity meter applicationFork Viscosity Meter product dimension

Installation case of WEpower electronic Wepower Electronic WPX301 Density meter site photo in differnet countrymirco motion viscometer WPX401 online site photodensitometer wepower WPX301
