Float Ball Switch
Float switches are used for precise and reliable liquid control in closed and open tanks. Wepower Electronic float switches are available in various types, easy to install, and one-piece products.
The Float Ball Switch produced by Wepower Electronic is an economical liquid level control device, which can easily sense the liquid level change in the tank. Wepower Electronic float ball switch is also called connecting rod type float ball switch. It is mainly installed in the tank and can be connected by flange or thread.
The floating ball of the float ball switch will be customized according to real conditions, and the float ball will float on the liquid surface. The float switch is very convenient to install and use. The float ball switch is used to detect the oil or water in the tank. When the liquid level reaches the set upper or lower limit, it will send an alarm.
What is a switch signal?
The switch signal generally refers to a normally open or normally closed signal. Float ball switch outputs switch signal when in use. The user can know the liquid level in the tank through the switch signal.
| Product | Float ball switch |
| Principle | float and magnetic level measurement |
| Model No. | WE-UQZ |
| Measuring media | Liquid (oil, water, alcohol, gasoline, diesel, lubricating oil etc.) |
| Medium density | ≥0.5g/cm3 |
| Output | Switch signal, normally open (NO) and normally closed (NC). |
| Contact type | SPST/ option SPDF |
| Contacting Rating | 50W/250VAC,200VDC 40W/250VAC 10W/110VAC |
| Contact Capacity | ≤70W |
| Temperature | -20℃~120℃;- 20℃~200℃(high temperature) |
| Working pressure | 0~3.5)MPa for metal type;(0~0.5)MPa for plastic type |
| Material | SS304/SS316/PP/PE/PTFE |
| Measuring range | 0-6000mm |
| Process connection | Flange :DN50/80/100 GB/ANSI/JIS
Thread Other-Clamp |
| Manufacturer | Wepower Electronic Made in China |
| Quality | 12-month warranty |
| Package | safe export carton |
