Float Switches For Water Tank
The float switch for water tank produced by Wepower Electronic is small in size and simple in structure, making it an ideal choice for water tanks. The water tank float switch is an economical and practical water level measuring device.
Features Of Float Switches For Water Tank:
A level switch that is positioned horizontally and uses the reed switch concept is called a Float Switch For Water Tank. The water float switch is designed for structures that contain just liquid or water. It performs incredibly well while measuring viscous greasy material. Float switches are easy to use regardless of the size of the water tank because they are usually mounted on the side. The volume is smaller and more flexible when compared to the rod-type float level switch mounted on the vertical top, and the manufacturing cost is also lower.
Advantages Of Float Switches For Water Tank:
▲Simple and effective level measurement
▲Point – level style water detection
▲Easy to install and operate structure
▲ Wide industrial working areas
| Product | Float switch for water tank |
| Model number | WPS series |
| Measuring media | Liquid (diesel, base oil, water, chemical solution, chemical reagent, LPG etc) |
| Wiring box | ABS aluminum |
| Output contact | 5A/220VAC |
| Contact form | SPDT（IC） |
| Type | Side-mounted threaded/flange type and top mounted threaded/flange type |
| Operating pressure | 15bar (side mounted)~ 30bar (special customization) |
| Operating temperature | -20~200°C , support high temp type |
| Wetted material | SUS304/316 |
| Applicable specific gravity | 0.65 side mounted /0.55 top mounted |
| Probe/Rod | Straight(standard) / L-shaped type |
Dimension:
Wiring:
