FMCW 80G Radar Level Meters
FMCW 80g radar level meter is high performance 76-81GHZ radar level transmitter. The FMCW radar level gauge can continuously measure the level of liquids and solids in storage tanks. Contact Wepower Electronic now to get high quality FMCW 80g radar level gauge.
Brochure of 80G Radar- Wepower Electronic
The measuring range of FMCW 80G Radar Level Meter can reach 150 m. Wepower Electronic FMCW 80g radar level meter supports 2 or 4 wire applications. 80g FMCW radar level meter varies depending on the size and model. It can range from 2.5 kg to 7.5 kg. Overall FMCW radar level meter is lightweight and easy to install. FMCW 80g radar level meter is compatible with a range of materials, including liquids, solids, and powders, and it is highly accurate, with an error margin of less than 2 mm.
Distinguish high-quality and low-quality FMCW 80g radar level meter:
► High-quality FMCW 80g radar level meter should have advanced signal processing capabilities
► High quality FMCW 80g radar level meter should have a high measurement accuracy and stability.
► A well-designed meter can measure a wide range of distances, from a few centimeters to several meters.
► A good meter should be able to withstand harsh conditions and have a long lifespan.
| Name | FMCW 80g radar level meter |
| Model | WERD- 92S |
| Medium | Powder/solid/dust |
| Antenna Type | PTFE; Lens(42/46/76mm) |
| Measure Range | 0-10m |
| Mounting | Universal flange with purging |
| Accuracy | ±2 mm |
| Response time | 0.4~0.6s |
| Display | LCD display |
| Beam angle | 3° |
| Microwave frequency | 76-81GHz |
| Output signal * | 4-20mA +HART / Others |
| Power supply * | DC 6-24V, AC 220V/50Hz |
| Material | Outer cover : aluminum, process : 304 stainless steel, |
| Pressure | -0.1~2MPa |
| Storage temperature | -40~+120℃ |
| Protection class | IP68 |
| Warranty | about 365 days |
