Stainless Steel Float Switch
WE-UQZ Stainless steel Float Level Switch is popular and widely used level controller , it can be installed on water tanks , fuel and other oil tanks .The magic float ball is made of stainless steel 304,316 or the other corrosion -proof material.
Advantages Of Stainless Steel Float Switch:
WE-UQZ Stainless Steel Float Level Switch is popular and widely used level controller , it can be installed on water tanks , fuel and other oil tanks .The magic float ball is made of stainless steel 304,316 or the other corrosion -proof material. Except water float level switch , water level float switch , UQZ Series float level switch can also used for corrosive liquids , such as aluminum sulfate liquids, the extra PTFE tube plays a protective role on the outside of the standard stainless steel rod. According to site field installation options , float type level switch sensor had thread and flange connection.
Stainless steel float switch has good reliability and high precision ±5mm ,and the maximum temperature can reach 180-200°C, it can be said that stainless steel float ball controller is the economical and practical level sensor for various industrial tanks which can be used durable and long time .
| Measuring range | 299-8999mm |
| Power supply | 24VDC |
| Output signal | 4-20mA |
| Accuracy | ±5mm |
| Medium density | 0.5-2g/cm3 |
| Working temperature | -40-100℃:; -20-200℃; |
| Pressure level | ≦10Mpa |
| Metal floating ball | ￠45, ￠52, ￠75 and other specifications |
| Wetted material | SUS304, SUS316L, PP, stainless steel rod with outer PTFE protecting pipes |
