Digital Density Meter For Liquids
Digital density meter for Liquids is specially designed for the needs of online denisty /concentration measuring for various liquids,even the corrosive acid chemical liquids,also available for static liquids and flowing liquids.WPX301 Online density meter is compact structure with higher accuracy, not easily affected by vibration and pressure changes of the liquids .
Digital Density Meter For Liquids is specially designed for the needs of online denisty /concentration measuring for various liquids , even the corrosive acid chemical liquids , such as alcohol , wine , brew , paper making , milk , slurry ,fuel oil , diesel etc .WPX301 Online density meter is based on tuning fork principle that vibration frequency by the fork probe . Compared with the traditional differential pressure principle density meter , our vibration digital density meter is compact and flexible with higher density accuracy 。
WPX301 digtial vibration density meter is not easily affected by vibration and pressure changes of the liquids . It is much smart and advanced density measuring in the industrial process. No matter flowing liquids or static liquids ,WPX301 ensure the good perfornance ,common flange and thread connecting and sanitary tri-clamp process connecting are for user options ,there is the built-in temperature sensor which provides temperature compensation as well .
| Product name | Tuning Fork Densitometer/Density Meter Online For Liquids |
| Measurement range | 0-2.5 g /cc (0-2500 kg/m3);，0~100.0% |
| Medium | Liquid;slurry , liquid mixture |
| Function | Test Density and Concentration online |
| Temperature range | -50 c ~+150 c |
| Accuracy | ±1-2kg/m3(± 0.002 g/cc ) |
| Max Working Pressure | 207bar (3000psi) |
| Medium Viscosity | 0-10000cp;Fluid viscosity range 0-2000cp |
| Power Supply | 24 V DC |
| Signal Output | 4 -20 mA，0-1000Hz，RS485 Modbus RTU |
| IP Grade | IP67 |
| Wetted Material | SS316/SS2205/Hastelloy C/ PTFE |
| Process Connecting | Flange (ANSI 150 ~1500 RF，DIN 50 PN16，DIN 50 PN40) /Tri- clamp /Thread |
| Disadvantage | not ideal for measuring crystallization and fouling media |
| Ordering Sheet | |||||||
| WPX301 | Vibrating Densitometer | ||||||
| / | CODE | Type | |||||
| A | Common | ||||||
| B | High Temp | ||||||
| C | Hygeian（Sanitary) | ||||||
| / | CODE | Length | |||||
| 01 | 150mm（Standard） | ||||||
| 02 | 200mm（Standard ） | ||||||
| 03 | Rod Extension 150mm～3000mm | ||||||
| / | CODE | Pressure | |||||
| D | 24V DC±10% | ||||||
| / | CODE | Material | |||||
| 1 | 316（Standard ） | ||||||
| 2 | 2205 | ||||||
| 3 | Hastelloy C | ||||||
| 4 | Anti-corrosive ，with coated PTFE | ||||||
| 5 | Other Customer Request | ||||||
| / | CODE | Process Connecting | |||||
| G | Dn50 PN16 316L | ||||||
| T | 1.5”G Thread | ||||||
| C | Tri-Clamp | ||||||
| F | Other Customer Request | ||||||
| / | CODE | Other Parameters | |||||
| A | Normal Temperature ℃ | ||||||
| B | Normal Pressure Kpa | ||||||
| C | IP Grade ：IP67 | ||||||
| D | Explosion-proof ：ExdⅡ CT5 | ||||||
| E | Temp:℃ | ||||||
| F | Pressure : Kpa or Mpa | ||||||
| （） | Other Customer Request | ||||||
| WPX301 | A | 01 | D | 1 | G | AB (Example ) | |
For learn more about our WPX301 Densitometer , please click photo below to our youtube video list :
