Din Rail Temperature Transmitter
The Din Rail Temperature Transmitter isolates the input, output, and power supply from one another while transmitting a thermocouple (TC) or thermal resistance (RTD) signal to an isolated current or voltage signal in one or two isolated circuits.
Features Of Din Rail Temperature Transmitter:
The Din Rail temperature Transmitter can be installed in the control cabinet to provide field instruments with signal isolation, conversion, distribution, processing, and other functions.The din rail temperature transmitter can be used in conjunction with modular instrumentation, DCS, PLC, and other systems to increase the immunity of automatic control systems in industrial production processes and guarantee system stability and dependability. This product features input/output magnetic isolation and 1 in/1 out, 1 in/2 out, and 2 in/2 outputs.
1 in/1 out
1 in/2 out
Parameters:
| Din Rail Temperature Transmitter | |
| Input | |
| Input Signal | RTD: PT100, Cu50 and other RTD signals |
| Thermocouple: K, T,E,J, N, R,S, B, Wre325, Wre326, BA1, BA2 | |
| Output | |
| Output Signal | 4-20mA; 0-20mA; 0-10mA; 0-5V; 0-10V; 1-5V; Customized |
| Output Load Resistance | DC current: 0~10mA: ≤700Ω; 4~20mA: ≤600Ω; 0~±10mA: ≤1kΩ; 0~±20mA: ≤500Ω |
| DC voltage: 0(1)~5V: ≥1MΩ; 0~10V: ≥2MΩ;0~±5V: ≥1MΩ; 0~±10V: ≥2MΩ | |
| Please specify your requirements before order if greater output load capacity is required | |
| Other Parameters | |
| Power Supply | DC24V,±10%;AC85-265V |
| Current Consumption | ≤70mA(1 in 1 out, 24V power supply, output 20mA); |
| ≤90mA(1 in 2out, 24V power supply, output 20mA); | |
| ≤100mA(2 in 2 out, 24V power supply, output 20mA); | |
| Accuracy | 0.2%F.S. |
| Response Time | Less than 0.5s |
| Temperature Drift | 0.005%F.S./℃ (-20℃~+55℃) |
| Isolation Intensity | 1500V AC/1min(between input-output-power) |
| Insulation Resistance | ≥100MΩ(between input-output-power) |
| Working Temperature & Humidity& Allowed Pressure | -20℃~+55℃ 10%RH~90%RH (40℃) 80kpa-106Kpa |
| EMC | Complies with GB/T 18268(IEC61326-1) |
| Applicable Equipment | 2-wires or 3-wires RTD |
| Signal Type | Measurements Range | Minimum Range | Output Accuracy | ||
| Thermocouples (TC) |
T | -200~400℃ | 25℃ | ±0.4℃/0.2% | |
| E | -200~1000℃ | 25℃ | ±0.4℃/0.2% | ||
| J | – 210~1200℃ | 25℃ | ±0.4℃/0.2% | ||
| K | -200~1372℃ | 25℃ | ±0.4℃/0.2% | ||
| N | -200~1300℃ | 25℃ | ±0.4℃/0.2% | ||
| R | 0~1768℃ | 100℃ | ±0.8℃/0.2% | ||
| S | 0~1768℃ | 100℃ | ±0.8℃/0.2% | ||
| B | 150~1820℃ | 100℃ | ±1.0℃/0.2% | ||
| mV input | -120~120mV | 10mV | ±10μV /0.2% | ||
| -1000~1000mV | 50mV | ±100μV /0.2% | |||
| Resistance Temperature (RTD) |
Pt50 | -200~850℃ | 10℃ | ±0.15℃/0.2% | |
| Pt100 | -200~850℃ | 10℃ | ±0.15℃/0.2% | ||
| Pt500 | -200~850℃ | 10℃ | ±0.1℃/0.2% | ||
| Pt1000 | -200~850℃ | 10℃ | ±0.1℃/0.2% | ||
| Ohm input | 0~500 Ω | 100Ω | ±0.2 Ω/0.2% | ||
| 0~4500 Ω | 100Ω | ±1.0 Ω/0.2% | |||
