2088 Pressure Transmitter
Industrial pressure transmitters instruments 2088 series have strong anti-interference with an IP65 sealing level, small size, and powerful performance. The general operating range of the 2088 type pressure transmitters can reach 100MPa, and the accuracy can reach 0.2%- 0.5%.
2088 pressure transmitter has undergone strict and precise temperature compensation, with stronger signal and more stable performance. Generally it is recommended to measure in the range of minus 20 degrees to 200 degrees Celsius.The actual instrument is incredibly portable and light.
2088 pressure transmitter can be attached to a measurement pipe or mounted directly on a pressure pipe. Positive and negative gauge pressure can be measured using the 2088 pressure transmitter series. Industrial pressure transmitters instruments 2088 series have strong anti-interference with an IP65 sealing level, small size, and powerful performance. The general operating range of the 2088 type pressure transmitters can reach 100MPa, and the accuracy can reach 0.2%- 0.5%. 2088 series compact pressure transmitter is real smart choice than 3051 Series pressure transmitter when the field working temperature is not big fluctuation, not high accuracy 0.1% required as well.
| Name | Digital compact pressure sensor 2088S & 2088M |
| Measurement Range (kPa) | -100kPa…0～10kPa…100MPa |
| Measuring medium | Liquid, gas |
| Application | Process, compressed air system, edible liquid/oil field |
| Accuracy | 0.25%, 0.5% |
| Ambient temperature | -10℃-70℃ |
| Medium temperature | -40-80°C; -40.-315°C |
| Diaphragm | To order |
| insulation | 100MΩ/250VDC |
| Pressure overload | 150%FS |
| Power supply | 24VDC |
| Output | 4～20mA, HART, MODBUS |
| Sensor filling oil | Silicon oil, fluorine oil |
| Electrical connection | M20x1.5 cable sealing head, NPT1/2 cable sealing head |
| Electronic housing | Aluminum alloy with sprayed surface |
| High pressure side filling fluid | Silicon oil, fluorine oil |
| Protection grade | IP65 |
Pressure measurement plays a vital role in industry, which is directly related to the stability, safety and efficiency of industrial production. Wepower Electronic is your reliable pressure measuring expert, contact us for learn more!
